SEMESTER 2 CHAPTER 3 SIMPLE HARMONIC OSCILLATIONS



SEMESTER 2             CHAPTER 3             SIMPLE HARMONIC OSCILLATIONS







EXAMPLES OF SHM  ,DEFINITION
https://www.youtube.com/watch?v=XjyOYluqnDM







QB.1)Which of the following graphs represents the acceleration(a) versus displacement (x) of a body in SHM?







Video on introduction to SHM


x-t , v-t and a-t graph of a body starting from mean position

Image result for x-t ,v-t and a-t graphs in SHM
x-t , v-t and a-t graph of a body starting from extreme  position
Image result for x-t ,v-t and a-t graphs in SHM
VIDEO for PHASE CONSTANT
https://www.khanacademy.org/science/physics/mechanical-waves-and-sound/harmonic-motion/v/phase-constant












































x-t graph of SHM if the object starts from mean position


X = A sin ωt                                                  x= displacement
A= amplitude
ω=angular frequency = 2πf

x-t graph of SHM if the object starts from extreme position


X = A cos ωt                                                   x= displacement
A= amplitude
ω=angular frequency = 2πf

DAMPED OSCILLATIONS
